SPECIFICATION

1) Electric Power Source : 380V 3Phase 60Hz (MAIN BREAKER 125A)

2) Total Current comsumption (Max) : 115 kw

3) Chamber temp. range : -50 ~ 180℃

4) Humidity Range : 30% ∼ 98%

5) Material

     a) Inside : SUS 304 1.2t Polyshed plate

     b) Outside : SS41 1.6t Steel plate with coating

6) Dimensions

     a) Inside : 2000 x 1800 x 1700 (WxDxH)mm

     b) Outside : 2590 x 2640 x 2420 (WxDxH)mm

7) Temp. & Humid. program controller

     * Model : TEMI-2500 / P.I.D auto tuning control / 120Pattern / 1200step

     * Communications : RS 232C

     * Fix & Program control

     * Trouble message system

8) Utility : D.I.Water 3/8“ hose connection, Drain 3/8“ hose connection

9) Safety Device

     * Electric leakage breaker
